AI in the Box
/ NDAA Compliant
  • Powered by the most advanced IDIS Deep-Learning Analytics (IDLA)
  • People Counting and Occupancy Control
  • Queue Monitoring
  • Heatmap
  • Social Distancing Violation
  • Mask Rule Violation
  • Generates real-time event notifications with high accuracy
  • Live Occupancy Dashboard to maintain capacity limits
  • Dashboard Reporting for visitor flow, checkout traffic, and compliance adherence
  • Rapid DirectIP plug-and-play installation
  • Simply connect to an IDIS NVR
  • Supports 4-ch IP cameras
Video Inputs4 IP Channels
Supported DeviceDirectIP NVR (Recording functionality is not included.)
VA SupportPeople Counting, Occupancy ControlQueue MonitoringHeatmapSocial Distancing ViolationMask Rule Violation
Video CompressionH.265, H.264
Network Connection100M Ethernet x 1 (100Base-TX) with PD100M Ethernet x 1 (100Base-TX) with PSE (PSE need Adaptor)
Operating Temperature0°C to 40°C (32°F to 104°F)
Operating Humidity0% ~ 90%
Power Input48V=, PoE
Power Consumption48V=, 0.8A, 38.4WPoE, IEEE 802.3at(Class 4), 25WDC OUTPUT : 48V=, 0.35A MAX
ApprovalFCC, CE, KC
Unit Dimensions (W x H x D)200mm x 44mm x 157.6mm (7.9" x 1.7" x 6.2")
Unit Weight0.88kg (1.94lb)
Installation environment Accessory configuration
