Driver Event Button

Anti-vandal Driver Event Button
  • 16mm diameter panel cutout
  • Single, Bi-color, and RGB LED options
  • Illuminated ring with laser etched power symbol graphic option
  • Multiple actuator options
  • IP65 rated, Off-(On), SPST
  • Soldered wire leads (300mm long) optional
General
Electrical Rating2A, 48VDC
Mechanical Life1,000,000 Cycles
Electrical Life50,000 Cycles
Contact Resistance50mΩ Max.
Insulation Resistance1000 MΩ Min.
Dielectric Strength2,000VAC
Operating/Storage Temperature-20°C to 55°C
Travel1.80mm (Non-Illuminated), 2.20mm (Illuminated)
Moisture ProtectionIP65
Contact ArrangementSPST Off-(On)
Actuation Force400 gf
Panel Thickness1-10mm
Mounting Nut Torque5-14Nm
INSTALLATION ENVIRONMENT ACCESSORY CONFIGURATION
Brochure Driver Event Button | Automatically Generate Datasheet
