12MP Panomorph IR Fisheye Camera
  • Easy installation with DirectIP NVR
  • 12MP Sensor / 9.4MP (3200 x 2944) resolution
  • Fixed-focal lens (f=1.2mm)
  • micro SD/SDHC/SDXC, Smart Failover (Up to 256GB)
  • Two-way audio
  • Alarm in / out
  • PoE (IEEE 802.3af Class 3), 12V DC
  • Day and night (ICR)
  • True wide dynamic range (WDR)
  • IR LED (Distance : 15m / 49.2ft)
  • Various viewing composition, 6 dewarping view modes
  • Supports ONVIF


12MP Panomorph IR Fisheye Camera
  • Easy Installation

  • 4K resolution

  • IR LED

  • Fisheye Lens






Image Sensor 1/1.7" 12MP CMOS
Max. Resolution 3200 x 2944
Scanning Mode Progressive Scan
Lens Type Fixed-focal
Focal Length f=1.2mm
Aperture F2.2
Iris Control Fixed Iris
Angular Field of View 180º(H), 180º(V), 180º(D)
Pan/Tilt/Zoom -
Min. Illumination Color : 0.2 lux @ F2.2 B/W : 0 lux (IR LED ON)
S/N Ratio 52.7dB
Dynamic Range 120 dB (True WDR)
Electronic Shutter Speed Auto / Manual (1/30 ~ 1/10000), Anti-Flicker, Slow Shutter (1~1/5, 1/7.5, 1/15)
Day and Night IR cut filter with auto switch
IR Distance (LEDs) 15m (6ea)
Image Setting Configurable Exposure, White Balance, Sharpness
Digital Noise Reduction Configurable 2DNR/3DNR
Backlight Compensation On / Off / HSBLC
Mirroring / Pivot -
Image Stabilizer -
Privacy Masking 8 Zones
Intelligent Video Video Motion Detection, Active Tampering Alarm, Trip Zone, Heatmap
Viewing Composition 1O, 1P, 1P2R, 2P, 4R, 1O7R
Video Out -
Video Compression H.265, H.264 (MP), M-JPEG
Intelligent Codec Supported
Bitrate Control H.264 - CBR / VBR, H.265 - CBR / VBR
Audio Compression ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law
Two-way Audio Yes
IP Camera Protocol DirectIP™ Mode : DirectIP Compatibility Mode : IDIS ONVIF Profile S
Max. Frame Rate DirectIP™ Mode : 15ips : 3200 x 2944 (WDR)
Compatibility Mode : 30ips : 3200 x 2944 15ips : 3200 x 2944 (WDR)
Supports Resolution DirectIP™ Mode : 3200x2944, 800x736
Compatibility Mode : 3200x2944, 2400x2208, 3200x1472, 1600x1472, 1600x736, 800x736
Multi-video Streaming DirectIP™ Mode : Quadruple Streaming
Compatibility Mode : Hextuple Streaming
Network Protocols DirectIP Protocol
Security SSL Encryption
Remote Access Client DirectIP NVR Connection
Ethernet RJ45 (10/100/1000BASE-T)
Recording Session Buffer Yes (Up to 60MB)
Edge Storage micro SD/SDHC/SDXC, Smart Failover (Up to 256GB)
Trigger Event Motion Detection, Alarm in, Audio detection, Tampering, Trip Zone
Event Notification Remote S/W, Email (with Image)
Audio In/ Out Line-in 1ea + Internal Mic 1ea / Line-out 1ea
Alarm In / Out Input 1ea / Output 2ea
Vandal Proof Casing -
Outdoor Ready -
Operating Temperature -10°C ~ +50°C (+14°F ~ +122°F) *Starting up at above 0°C (32°F)
Operating Humidity 0% ~ 90%
Power Source 12VDC, PoE (IEEE 802.3af Class 3)
Power Consumption 12V=, 1A, 12W PoE, IEEE 802.3af(Class 3), 12W
Label 12V=, 1A, 12W PoE, IEEE 802.3af(Class 3), 12W
Approval FCC, CE, KC
Dimensions (Ø x H) Ø155.0mm x 52.8mm (Ø6.10" x 2.08")
Weight 0.815 kg (1.79 lb)
[Brochure] DC-Y8C13RX
[A&E Specification] DC-Y8C13RX A&E Specification v1.0
