DA-PI PoE400

Single Port High-PoE Injector
  • Up to 90W of PoE Power
  • Compatible with IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
  • Protects low power devices to receive only the power they need
  • Automatic detection and protection of non–standard ethernet terminals
  • Support 10/100/1000 Base-T Lan environment
RJ45 Ethernet Interface_DATA In
port1 ch
ConnectivityRJ45
Wire Type CAT5 or better
DistanceUp to 100m
Transper Speed10/100/1000Mbps
RJ45 Ethernet Interface_PoE
port1 ch
Pin Assignment and PolarityOUTPUT #1(OUT) 3/6(+), 1/2(-)

OUTPUT #2(OUT) 4/5(+), 7/8(-)
PSE Power56V DC, Max. 90W
Installation environment Accessory configuration
Brochure PoE400
Brochure DA-PI PoE400
