DP-DD1316

DirectIP™ 16-channel Decoder
/ NDAA Compliant
  • Supports IDIS IP Camera
  • Supports HDMI, VGA, CVBS port
  • Up to 480ips live display
Video
Video Inputs16 IP Channels
Max. ResolutionUp to 12MP (Depending on IP Camera)
Supported DeviceIDIS IP Camera
Video Outputs1 HDMI, 1 VGA, 1 CVBS
Display ResolutionHDMI : 3840x2160, 2560x1440, 1920x1200, 1920x1080, 1680x1050, 1600x1200
VGA : 2560x1440, 1920x1200, 1920x1080, 1680x1050, 1600x1200
C[removed] 720x480(NTSC) , 720x576(PAL)
Display SpeedUp to 480ips
Network
Video CompressionH.265, H.264
Max. Incoming Throughput90Mbps
EthernetGigabit Ethernet x1
Environmental
Operating Temperature0°C ~ 40°C (32℉ ~ 104℉)
Operating Humidity0% ~ 90%
Electrical
Power Source12VDC, PoE
Power Consumption12V=, 1.4A, 16.8W
PoE, IEEE 802.3at(Class 4)
ApprovalFCC, CE, KC
Mechanical
Dimensions200mm x 44mm x 153mm (7.9" x 1.7" x 6.0")
Weight0.78kg (1.72lb)
Installation environment Accessory configuration
Manual DP-DD1316 Manual v1.0 Download
Software DP-DD1316 Firmware v8.5.1_JAPAN Download
Software DP-DD1316 Firmware v8.5.1 Download
Brochure DP-DD1316 | |Automatically Generate Brochure
Download
